The category in a plugin is not a label. It is the routing rule.

Sixty two first party packages ship today, in exactly six categories: 27 widget, 15 library, 10 ui, 5 graphics, 3 dbs and 2 framework. The category is not a naming convention and it is not a tag. It is a plugin_type field on the plugin record, and three separate systems read it: the editor decides which socket the plugin turns up in, validation decides which files it has to export, and the runtime decides which of three execution surfaces its code runs on. Nothing is wired up by hand after an install. One package in the catalog proves the field is the authority rather than the name, because its directory and its exports both say widget while its published npm name says ui, and every surface in Studio routes it by the field. A new project starts with two plugins already installed, the native data driver and the Tailwind framework. Everything past those two is one install, and the category decides where it lands.

Six categories, six different sockets

A child plugin needs its parent to name it back

Third party server code is refused by default

The category in a plugin is not a label. It is the routing rule.

Plugin packages shipped, across exactly six categories

111

Methods declared by the 42 packages that export any, over 632 fields

Filenames the platform probes for after an install. Most ship two

Packages that ship server code. No widget or ui plugin does

The routing rule

Six categories, and the category decides both ends.

Install one and it turns up in the right place with nothing to configure, because a single field is read by six different pieces of the editor and by three different runtime entry points. The picture below is the contract, not the picker: on the left is how a plugin of that category is reached, and on the right is the exact export the runtime calls and with what signature. Read it as six independent contracts hanging off one field rather than as one plugin interface with six flavours, because that is what it is. A widget and a ui plugin do not export the same shape, do not receive the same arguments and do not appear in the same place, and a graphics plugin does not even ship the file the other five build around.

plugin_type, on the record

the field the platform reads, not the word in the package name

the insert panel drops one element

An xu-widget node carrying the plugin id and a method name

widget, 27 shipped

grids, calendars, charts, scanners, Stripe elements

runtime.mjs, one exported function per method

The method function, handed a container node it owns

a switch per plugin in the properties panel, per element

An xu-ui-plugin attribute, opt in on that one element

ui, 10 shipped

date pickers, phone parsing, sorting, tooltips

runtime.mjs, exactly one export named fn

fn(plugin_name, element, properties), decorating a node you already have

a workflow action, and an AI agent tool

call_library, naming the plugin and the method

library, 15 shipped

Stripe, Twilio, Firebase, docx, xlsx, pptx, and the AI app builder

a browser stub that posts, and a server file that works

server.mjs, one export per method, handed the setup document

the icon picker, first installed kit selected for you

No index.mjs at all: the thinnest contract of the six

graphics, 5 shipped

Feather, Heroicons, Iconoir, Phosphor, Tabler

runtime.mjs, one exported tabs array

Inline icon items, or directories inside its single dependency

databaseSocket on the table, plus a connection id

Creating a table picks the driver

dbs, 3 shipped

Xuda, CouchDB and MySQL

server.mjs, dispatched by service name

read, create, update, delete, restore, check_unique, and a connection test

chosen when you create a component

The UI Framework select, listing the installed ones

framework, 2 shipped

Ionic and Tailwind, one active per app

core is mandatory or the plugin is refused by name

core decides the app root tag, and its resource list is unloaded on a swap

Two footnotes, both checkable. The category is a field on the record and not the word in the package name, and one package proves the difference: its directory and its contract say widget, its published npm name says ui, and every socket above routes it by the field. And the Installed badge above the insert panel does not count all six categories. It counts framework, graphics and widget only, because those three are the ones that contribute something droppable.

The contract

One contract, six shapes, and the empty cells are the argument.

After the npm install the platform probes for six filenames, index.mjs, setup.mjs, studio.mjs, runtime.mjs, server.mjs and style.css. It looks at the package root first and then inside dist, records which of the two it found so the runtime knows whether to also load the built stylesheet, and then imports every file it found except style.css and server.mjs. That import is the real does this load check: a plugin whose index.mjs throws while being imported fails validation right there and lands with the error text stored on its record, which is why a broken plugin shows you a reason rather than a blank slot. The table below is what the six categories actually ship. The crosses carry as much of the argument as the text does: the server.mjs column is empty for every browser facing category, which is the fact the execution surfaces and the third party gate both rest on. One file is left out of the table deliberately. studio.mjs is shipped by exactly one package in the whole catalog, the native data driver, where it is a separate design time server surface for the editor, so it gets this sentence instead of a column of five crosses.

	index.mjs must export	runtime.mjs must export	server.mjs	setup.mjs
widget, 27 shipped	methods, plus optional capabilities	one function per method
library, 15 shipped	methods	one stub per method	12 of 15	12 of 15
ui, 10 shipped	properties	fn, and optionally destroy
graphics, 5 shipped		tabs
dbs, 3 shipped	tabs and public_filter		3 of 3
framework, 2 shipped	tabs, core and the UI primitives	core, mandatory. resources, optional

Installing

An install is a real npm install into a directory that belongs to your project.

Nothing here is a metaphor for an install. An entry is written into the map of purchased plugins on the project, carrying the installed flag, the version, the name of the parent plugin where there is one, the file manifest, the plugin type and the background flag. Then npm install runs inside a plugins directory belonging to this project alone, with every argument shell quoted. Then that directory is rsynced out to the regional servers. Then the installed package is scanned to depth ten and every file is read into a CouchDB database that belongs to the project, keyed by its relative path, and an existing setup is carried across the update rather than overwritten.

Every project gets its own node_modules tree, and a package that fails to fetch removes only itself. There is a note in the code saying why: an earlier version deleted the whole tree on a failure, which uninstalled every other plugin the project had because one package could not be downloaded.
Uninstalling flips the installed flag, runs npm uninstall, and blanks the project side plugin document down to its id, its revision and its setup. Configuration survives an uninstall and a later reinstall, which is the difference between removing a plugin and losing the credentials you typed into it.
Nothing is bundled into an app build. The runtime fetches each plugin file per session over a /plugins route, which serves out of the per project tree and requires either a resolvable app id or a valid token. For an unbundled source file that route rewrites the relative ESM imports on the way out, so a browser can load them at all. What deploy bundles is the setup map, collected into the app startup data.
In a dev session the runtime tries src before dist for any .mjs file and falls back to dist, so editing plugin source shows up without a rebuild. Everywhere else the manifest decides, and where it records that the built copy was the one found, dist wins.

One install

The record is written
installed, version, parent name, file manifest, plugin type and the background flag
npm install runs
Into the plugins directory for this project alone, every argument shell quoted
The tree is synced out
That project plugin directory is pushed to the remote regional servers
The package is snapshotted
Every file read into the project database, keyed by its relative path

Composition

A child plugin names its parent. The parent has to name the child back.

A plugin may declare one parent, and the platform refuses to install it unless two separate declarations agree. The child names the parent through a dependency field on its own record. The parent has to list the child back, in an authorized plugins array on the parent record. Neither declaration is enough on its own. The checks run in order and each failure comes back as a numbered refusal rather than a stack trace, and all of them run before npm is invoked, so a rejected install leaves nothing behind on disk. The same two checks are re-run later, on every read and every write of a plugin configuration, and again on the server before a plugin method is allowed to execute.

Load the record

By package name, out of the plugin registry database

Exit

minus one

No plugin by that package name exists in the registry, and the refusal names the package it could not find.

Free only, if asked

The path that seeds a brand new project passes a free only flag

Exit

minus two

This plugin carries a price and the caller asked for free plugins only. That caller is the routine that seeds a new project, which is why a new project cannot quietly acquire a paid dependency.

Is the parent installed here?

Checked only for a plugin that names one

Exit

minus three

The named parent is not installed on this project. Install the parent first and the same call succeeds, with nothing else changed.

Does the parent list this child?

An authorized plugins array, on the parent record

Exit

minus four

The parent is installed, but its own record does not list this child. This is the half that no amount of work on the child can satisfy, and it is the point of the pair.

Write, install, sync, snapshot

The record first, then npm, then the fleet, then the project database

The pair decides two things beyond permission. A child has its configuration lookup redirected to the parent document, so there is exactly one Stripe configuration rather than one per widget that draws a card field. And it decides trust: because the server merges the parent server file into the same object as the child, a first party plugin that depends on a third party one counts as third party.

Configuration

The plugin decides what its own configuration may tell the browser.

Plugin configuration is not held in the shared registry. It lives as a setup document inside the CouchDB database of the project that configured it, written by the setup form and read back by both sides. When the read is a public one, the platform imports the plugin and calls a function the plugin exports itself, and sends back only what that function returned. There is no platform wide allow list of safe keys, and that is both the strength of the arrangement and its limit: the plugin author is the one who knows which of the fields is the secret, and the plugin author is the one who writes the filter.

One setup document, in your project database

Written by the plugin setup form, read back by both sides, and preserved across an uninstall.

On the regional server

The unfiltered document.

Stripe, both keys

The accounts tab declares a public key and a secret key, both of them mandatory. The server file builds the Stripe client from the secret one, and that file is the only place it is read.

MySQL, the whole connection

The connections tab declares host, user, password, database and port. Four of the five are mandatory.

The filter is plugin code

public_filter is exported from the same file that declares the very fields it filters, the index or setup file inside the plugin package.

A child reads the parent document

A plugin that names a parent has its setup lookup redirected there, in both the platform side and the runtime side implementations, so there is one configuration and not two.

In the browser

Whatever the filter returned.

The public key alone

The payment element widget reads the public key out of the filtered setup by account id. The secret key has no path to this side at all.

An empty object per connection

The browser learns that a connection exists and what its id is. Not the host, not the user, not the password, not the database, not the port.

So the rule is per plugin

Nothing platform wide decides this. A plugin that exports no filter sends its setup document through unchanged.

And a child sees the parent filter

The Stripe elements widget reads the parent public key through the filter the parent exports, which by construction returns no secret.

The honest reading is that this boundary is exactly as good as the plugin that drew it. An absent filter means an unfiltered document, and the platform does not second guess that. The same setup document is what the deploy step collects, one entry per installed plugin, into the startup data an app is built with.

Execution

Three surfaces, and the server one is checked before the import, not after.

Plugin code runs in exactly three places. In the browser, as a widget that owns a container the runtime made for it, as a ui plugin decorating an element you already had, as a framework, or as a background plugin hooked onto the app lifecycle. On a dedicated plugin service, its own process on port 3008, for library server methods. And on a separate dispatch for the data drivers, which never goes through that service and caches its live connection per app and per plugin. Both server paths execute under a sixty second ceiling.

A library method is two files doing two jobs. The browser stub casts the declared fields, enforces the mandatory ones and posts; the server file does the work and holds the credential. That split is the whole reason a Stripe secret key has no browser path: it is read in server.mjs, out of the setup document handed in, and nowhere else.
Before the service loads a plugin server file it asks whether the publisher is first party, and it asks before the import rather than after. Importing a module already runs its top level code, so a check placed after it checks nothing. Third party server methods are refused by default and the switch that would allow them is set to false in both configurations, so third party plugins are a browser side product surface today.
A background plugin gets five lifecycle hooks, fired in the order beforeInit, initialized, beforeMounted, mounted and systemReady around app start, each one handed the session, the app object, the api and the setup data. The run in background checkbox is offered only on a library plugin, and registration is skipped entirely in slim bundle mode.
The fields a method declares do double duty. On a Full Stack VPS the platform walks the installed plugins and registers every method as an MCP tool, named plugin then method, with its input schema built from those same declared fields and its description taken from the tooltip the method already carried.

One library call

The workflow step fires
Naming a plugin, a method and the properties for it
The browser stub validates
Fields cast to their declared types, the mandatory ones enforced
It posts to the plugin service
The token checked against a live session in your own project database, never from a cache
The server file runs, with a ceiling
Sixty seconds, with the setup document handed in

What plugin code can reach

A browser plugin is handed one object, and this is all of it.

The runtime builds one parameters object per call and hands it in as the second argument. A widget does not reach for a global to find the platform, and there is no separate plugin API to learn beyond what arrives in that object. The host creates the container div, reads the plugin id and the method name off the node, imports index.mjs and checks the declared capabilities against the current environment, resolves and casts every declared field and enforces the mandatory ones, loads style.css and dist/runtime.css when the manifest recorded them, fetches the plugin setup, and only then imports runtime.mjs and awaits the method. A throw inside that method is caught and reported rather than left to take the page down. The shape below is the widget one. A ui plugin gets something different enough that it is worth printing beside it, because that difference is the whole distinction between the two categories: a widget is given a container it owns, a ui plugin is given an element you already had.

runtime.mjs · export async function <method>(fields, params)

fields the declared fields, cast to their types and checked

params:

SESSION_ID, method, _session

dsP, sourceP, propsP datasource, source row, resolved props

plugin_name

container_node the div the runtime made for this widget

container_data

plugin_setup the filtered setup, never the raw document

report_error(desc, warn)

log_error(desc, warn)

call_plugin_api(name, data) the only route to the server

set_SYS_GLOBAL_OBJ_WIDGET_INFO(doc)

run_widgetCallbackEvent() fires the event id you declared as a field

api_utils

a ui plugin gets a different shape entirely:

fn(plugin_name, element, properties) no container, it decorates yours

This is a calling convention, not a sandbox. Widget code runs in your page like any other script on it, and what the object buys you is that the platform decides what goes in. A ui plugin may also export destroy, to release whatever it built when its element goes away, and the runtime replays the exact properties fn was handed rather than re-resolving them at teardown, because by then the datasource behind that row may already be retired.

Building one

The developer path is npm, and nothing about it is homegrown.

There is no proprietary toolchain here and no plugin CLI to learn. The whole path is a published sandbox package you develop against, a plain Vite library build, and npm. The platform only meets your plugin at the end of it, when you register the package name.

01
Develop against the sandbox
The harness is a real published package, @xuda.io/plugin-sandbox at version 1.0.27. It builds a two pane page: a Plugin Configurator form on the left, generated from the fields your method declares, a drag resizer in the middle, and a Live Preview pane on the right with the container div your method will be handed. A dropdown picks which of your methods to test. Any field declaring the editor render type gets a real Monaco editor wired to its change event, with the language taken from the render params and javascript as the default. Adoption is partial and worth stating plainly: thirteen of the sixty two shipped packages develop against it, and twenty ship a test page of their own under tests.
02
Build with Vite, into dist
Every sandbox using package carries the same vite config. The library entry is src/runtime.mjs, the format is ES, dynamic imports are inlined, the output lands in dist, any emitted stylesheet is renamed to runtime.css, and a small copy step moves everything in src except runtime.mjs into dist alongside it. That convention is exactly why the platform records a dist flag and a css flag per file when it probes your package, and why the runtime knows to load dist/runtime.css as well as the module.
03
Publish, then register it
All sixty two shipped package.json files carry the identical publish script: npm version patch, then npm publish. Plain semver with nothing layered on top, and the high water marks say how much use that gets. The native data driver is on 1.0.320, the Tailwind framework on 1.0.128, the AI app builder on 1.0.74. Registering with the platform is a separate step that pulls the live manifest from npm, takes the version from there rather than from your form, and takes the marketplace icon out of the svg_icon field in your package.json if you left the icon on the form blank.

The other path

Or describe it, and the plugin system builds a plugin with a plugin.

The builder is not a tool the chat assistant can reach on its own. Both of its methods are marked private, so nothing exposes them as agent tools; the plugins tab stages the action and the assistant runs it as part of that job. The thing that does the work is itself a shipped library plugin, the studio AI app builder, called the same way any other library method is called. Every constraint below is in the generator rather than in a policy document, and the terminal state is a private plugin, on purpose.

The type is normalised

One of six exactly, stricter than the registration form allow list

Exit

invalid type

Anything outside the six throws by name

Exit

not a hosted plugin

A modify refuses a plugin that was not built this way

A schema constrained agent runs

Eight turns, told not to use child process, fs, eval, Function or the environment

The file list is an enum

Seven filenames, no directories and no traversal, checked again on write

The merge is surgical

Existing files first, generated ones over the top. package.json, index.mjs and runtime.mjs cannot be deleted, and scripts and dev dependencies are stripped

Thirteen patterns are scanned

Any match aborts by naming the file and the pattern that matched

Exit

the build stops

A modify never regenerates from scratch, because that would wipe the files it was asked to change. The failure is surfaced instead

Packed, hashed, registered private

A real npm tarball, a sha256 and an integrity string, uploaded with the review gate skipped

The versions state the intent: a created plugin is 0.1.0 and a modify bumps the patch. It gets its own npm scope rather than the first party one, it installs from the artifact rather than from the registry, and going public is a separate explicit action on the plugin card, which is what the assistant reply says in as many words. Now the honest correction. That scan is a static pattern match over generated text, sitting on top of a response schema and a seven filename allow list. It is not dynamic analysis and it is not a sandbox.

Who may do what

Five actions, and no two of them are gated the same way.

Two of these are routinely described as one thing, and they are not. An Agency membership gates registering a plugin at all, and it sits on the upload method. An active Stripe Connect seller account gates going public, and it sits on the publish method, which anyone signed in may call. They stop different people at different moments. Installing a plugin onto a project is gated by neither: it needs admin clearance on that project, and if the plugin carries a price it routes through a payment step first.

	Clearance	Membership plan	The other gate
Install or uninstall on a project	Project admin		A priced plugin routes through a payment step first
Read or write a plugin configuration	Project admin		The parent chain is rechecked before anything is touched
Register a plugin at all	Project admin	Agency	Ownership enforced on every update
Publish it to the marketplace	Any signed in user		An active Stripe Connect seller account, or a 403
Archive it	Project admin		Owner only

The gate

Publishing is a separate action from updating the code, deliberately.

Uploading a new version, or letting the AI builder rebuild one, never re-enters review. The existing lifecycle is carried forward verbatim: a plugin that was private stays private, a plugin that was public stays public, and the review state it already held is the review state it keeps. Going public is a different method with a different clearance, run once, by the owner, on purpose, and it is the only call that runs the gate. Everything below hangs off that one call.

The publish gate

run on the explicit publish, never on a code update

Refused, before the reviewer is asked

checked in the interface, then again on the server

A Stripe Connect seller account that is not active, refused with a 403

the first wall most people meet, and it is not about the plugin

account standing

Not active, suspended, terminated, on a billing hold, or flagged for abuse

a deterministic check, rejected at full confidence before the reviewer is asked anything

Published

on the verdict

approve

Confidence of 85 or more, with nothing flagged high severity

the only automatic route onto the shelf

Held for a person

the busiest outcome here

demoted

An approval under 85, any high severity flag, or a refusal under 60

three separate things land in it

fail safe

The reviewer was unreachable, and the gate never publishes by default

recorded with that reason, and the plugin waits

Never runs the gate

Never reviewed at all

A private update or an explicit skip: the lifecycle carries forward untouched and the plugin stays owner only. It is the ordinary code update path, and the one most versions take.

Ten checks come back from the reviewer, each carrying its own severity: bot activity, undisclosed commercial intent, harmful code, suspicious activity, a malformed account name, spam and low quality, impersonation and trademark, prohibited content, plagiarism and duplication, and leaked secrets or personal data. What the reviewer is handed is worth stating plainly, because it sets the ceiling on what any verdict can mean: the name, the description, the tags, the category, the price, and a code summary that is the npm package name, its version and the platform list. It is a metadata review, not a read of your source. A first party publisher skips it outright. Anything held goes to a person, with an operator email, a support ticket deduped on the item id, and an appeal link on a rejection, and there is no turnaround target written anywhere in the code.

Honest limits

Nine things the plugin system does not do.

Third party plugins cannot run server code today. The interim policy is deny, it is a config switch, and that switch is off in both configurations, so anything you build for someone else to install is a browser side surface only.
The widget contract carries a headless capability, for plugin code that runs where there is no document. Not one of the 62 shipped packages declares it. The contract is there, the shipped proof is not.
The runtime supports an optional destroy export on a ui plugin. None of the ten shipped ui plugins exports one.
Two of the three data drivers are read only as shipped. Only the native one implements all six services. MySQL and CouchDB export a read and a connection test and nothing else, and asking either for anything more throws by naming the missing service.
The icon picker searches inside the kit you have selected, not across the kits you have installed. And a graphics plugin may declare at most one npm dependency, which is why every shipped kit is one upstream package and its directory tree.
Installing a shared component checks only two kinds of plugin dependency, the interface framework on a program and the data driver on a table. A component that uses a widget plugin does not declare it, so that install can succeed with the widget still missing.
The AI builder is guarded before the code is packed, never while it runs. Thirteen forbidden patterns and a fixed enum of filenames, both applied to text. There is no runtime isolation waiting behind them.
Nothing in the platform decides which configuration keys are safe to publish. That judgement is delegated wholly to the plugin author, and a plugin that makes no judgement hands its whole configuration document to the browser.
The registration path accepts two more type strings than the product exposes, and nothing in the catalog ships either of them. The six in the picker are the six that route anywhere.

Before you commit

The questions you are forming right now

Five of these six answers end on a limit. They are here because you would meet them in the first week anyway.

Watch

Watch a plugin install and appear in its socket.

Install two plugins and you have a data layer and a design system.

That is literally what a new project ships with: the native data driver and the Tailwind framework, and nothing else. Everything past those two is one install, and the category on the record decides where it turns up, whether that is the insert panel, the icon picker, the table driver select, a switch on one element, or the workflow action list.

The category in a plugin is not a label. It is the routing rule.

Six categories, and the category decides both ends.

One contract, six shapes, and the empty cells are the argument.

An install is a real npm install into a directory that belongs to your project.

A child plugin names its parent. The parent has to name the child back.

The plugin decides what its own configuration may tell the browser.

Three surfaces, and the server one is checked before the import, not after.

A browser plugin is handed one object, and this is all of it.

The developer path is npm, and nothing about it is homegrown.

Develop against the sandbox

Build with Vite, into dist

Publish, then register it

Or describe it, and the plugin system builds a plugin with a plugin.

Five actions, and no two of them are gated the same way.

Publishing is a separate action from updating the code, deliberately.

Nine things the plugin system does not do.

The questions you are forming right now

Do I have to wire a plugin up after I install it?

What can plugin code in my app actually see?

How do two plugins compose?

Do I have to learn a new toolchain to write one?

What does the AI builder actually hand me?

What does it cost to publish one?

Watch a plugin install and appear in its socket.

Install two plugins and you have a data layer and a design system.
